PostgreSQL Replication Sandboxes with ProxySQL via dbdeployer

At Percona Live Bay Area 2026 we presented ProxySQL – A Perfect Complement to Your PostgreSQL Database and described how ProxySQL can act as a PostgreSQL data gateway offering connection pooling, read/write routing, and proxy-side observability in one place.

dbdeployer is a long-time established product for MySQL sandboxes. You can now quickly deploy PostgreSQL sandboxes; covering versions 12-18; and ProxySQL 3.0.x in three steps. The entire flow takes a few minutes once a Linux VM is provisioned with some depencency packages. Sandboxes are user-based and do not require any superuser privileges.

Three Steps

GET: Download database binaries for your version.
UNPACK: Prepare the binaries by unpacking into per-user environment ~/opt/postgresql/<version>
DEPLOY: Use the ready components to create a variety of topologies, such as a single node, primary/replica setups, or multi-node clusters available in /sandboxes/<name>.

DB Deployer 3 Steps

For convenience and timing in a conference presentation setting, the VM demo environments were created on a Mac using OrbStack without the need to provision a cloud-based VM. In a later post we will publish instrutions for cloud-based VM deployments.

Prerequisites

On your Mac:

brew install orbstack
orbctl version
orbctl create --help

Supported distros: alma  alpine  arch  centos  debian  devuan  fedora  gentoo  kali  nixos  openeuler  opensuse  oracle  rocky  ubuntu  void
Supported CPU architectures: arm64  amd64

You also need the demo cloud-init file dbdeployer.yaml currently available here.

Step 0 — Provision the VM

The following presentation examples work with Ubuntu (e.g. 24.04) and Debian OS (e.g. 12).

DISTRO="ubuntu"
VERSION="24.04"
VM_NAME="${DISTRO}$(echo ${VERSION} | tr -d '.')"
CLOUD_INIT="dbdeployer.yaml"

orb create ${DISTRO}:${VERSION} ${VM_NAME} -c ${CLOUD_INIT}
orb -m ${VM_NAME} tail -50 /var/log/cloud-init-output.log

When the launch and cloud-init finishes you can spot check dependencies and possible PostgreSQL versions available for the OS:

ssh ${VM_NAME}@orb
dbdeployer --version
proxysql --version
apt-cache search postgresql | grep -E '^postgresql-[0-9]+ ' | sort

Using the Linux Download instructions the following are available.

postgresql-10 - The World's Most Advanced Open Source Relational Database
postgresql-11 - The World's Most Advanced Open Source Relational Database
postgresql-12 - The World's Most Advanced Open Source Relational Database
postgresql-13 - The World's Most Advanced Open Source Relational Database
postgresql-14 - The World's Most Advanced Open Source Relational Database
postgresql-15 - The World's Most Advanced Open Source Relational Database
postgresql-16 - The World's Most Advanced Open Source Relational Database
postgresql-17 - The World's Most Advanced Open Source Relational Database
postgresql-18 - The World's Most Advanced Open Source Relational Database

Step 1 — Get the binaries / Step 2 - Unpack the binaries

For simplicity of versions 12-18, we combine these one-off steps on your VM.

apt-get download libpq5
for PG_VERSION in $(seq 12 18); do
  echo "Prepping ${PG_VERSION}"
  apt-get download postgresql-${PG_VERSION} postgresql-client-${PG_VERSION}
  dbdeployer unpack --provider=postgresql postgresql*${PG_VERSION}*.deb libpq5_*.deb
done
echo "Installed binary versions  $(ls ~/opt/postgresql | tr '\n' ' ')"

This provides these possible versions for PostgreSQL sandboxes.

Installed binary versions  12.22 13.23 15.18 16.14 17.10 18.4

Step 3 — Deploy a replication topology with ProxySQL

Pick a version you unpacked (example: PostgreSQL 18.4) and you can deploy a variety of different configuration topologies with a single command. The following replication is the default HA topology with a primary and 2 replicas.

PG_VERSION=18
PG_MINOR_VERSION=$(basename $(ls -d ~/opt/postgresql/${PG_VERSION}* | head -1))

dbdeployer deploy replication ${PG_MINOR_VERSION} \
  --provider=postgresql \
  --sandbox-directory=demo${PG_VERSION} \
  --with-proxysql \
  --force

This creates 3 PostgreSQL servers, a ProxySQL server and simpled name commands to leverage:

Component	Location	Port (PG 18.4 example)
Primary	`~/sandboxes/demo18/primary/`	16804
Replica 1	`~/sandboxes/demo18/replica1/`	16805
Replica 2	`~/sandboxes/demo18/replica2/`	16806
ProxySQL admin	`~/sandboxes/demo18/proxysql/`	6132
ProxySQL proxy	same	6133

Each node gets lifecycle scripts including: start, stop, status, restart, use, bench.

For the topology several other scripts available include check-replication and test-replication.

Verify replication

cd ~/sandboxes/demo18

./check_replication
./test_replication

Connect directly to the primary:

./primary/use -c "SELECT version();"

Connect through ProxySQL admin (PostgreSQL protocol):

./proxysql/use -c "SELECT 1"

Connect through the proxy port as the application user:

./proxysql/use_proxy -c "SELECT 1"

Benchmarking

The topology includes a bench helper that initializes a small TPC-B dataset (if needed) and runs a 30-second pgbench benchmark against the default rsandbox database.

** Connecting directly to the Primary:**

./bench

Connecting through ProxySQL:

./bench --proxysql

Verifying traffic

In a separate window an easy way to monitor WAL operations is:

watch --differences ./check-replication

When using ProxySQL, you can connect to the ProxySQL admin interface and monitor connection and statement operations via SQL.

./proxysql/use

Connection pool status

SELECT
    hostgroup,
    srv_host,
    srv_port,
    status,
    ConnUsed,
    ConnFree,
    ConnOK,
    ConnERR,
    MaxConnUsed,
    Latency_us
FROM stats.stats_pgsql_connection_pool
ORDER BY hostgroup, srv_host;

Top queries by execution count

SELECT
    hostgroup,
    database,
    username,
    client_address,
    SUBSTRING(digest_text, 1, 50)           AS digest_short,
    count_star                              AS executions,
    sum_time                                AS total_time_us,
    ROUND(sum_time / count_star, 0)         AS avg_time_us,
    min_time                                AS min_time_us,
    max_time                                AS max_time_us,
    sum_rows_affected,
    sum_rows_sent
FROM stats.stats_pgsql_query_digest
WHERE digest_text LIKE 'SELECT%'
ORDER BY executions DESC, avg_time_us DESC
LIMIT 5;

Top queries by total backend time

SELECT
    hostgroup,
    SUBSTRING(digest_text, 1, 50) AS digest_short,
    count_star AS executions,
    sum_time AS total_time_us,
    ROUND(sum_time / count_star, 0) AS avg_time_us
FROM stats.stats_pgsql_query_digest
ORDER BY sum_time DESC
LIMIT 20;

Watch stats live (Linux VM)

You can save a query to a file, and you can watch the traffic with:

watch -n 2 --differences 'bash ./proxysql/use -f /tmp/pgsql_digest_top5.sql'

Ongoing development

PostgreSQL sandboxes currently work using apt packages on Ubuntu/Debian platforms. Providing rpm options for CentOS/RedHat/Fedora is currently planned.

What’s next

Read the PgBouncer → ProxySQL migration series for benchmark comparisons and routing depth
Try the Docker tutorials for container-based walkthroughs
Follow dbdeployer development at github.com/ProxySQL/dbdeployer

This demo environment is designed for local evaluation, conference workshops, and reproducible benchmarks — the same workflow we used on stage at Percona Live, now in a form you can run on any Mac with OrbStack.
